Рама GA10157 секція Shank W/Gauge Wheel Pivot Spindle Kinze станина ga10157 корпус

SHANK ASSEMBLY, SEED TUBE AND
DEPTH ADJUSTMENT
ITEM PART NO. QTY. DESCRIPTION
(Per Row)
1. G11015 2 Hex Washer Head Cap Screw, ⅜"-16 x 1¼"
2. GB0274 1 Cover, Depth Adjustment
3. GB0266 1 Handle, Depth Adjustment
4. GB0267 1 Lever, Depth Adjustment
5. GD3612 1 Cap Plug
6. GD10993 1 Spring
7. GD13361 1 Pin, ⅜" x 1⅔"
8. GD11259 1 Sleeve, ⅜" I. D. x ⅝ "O. D. x 1 25∕32" Long
9. G11008 1 Hex Head Cap Screw, ⅜"-24 x 2 ½" Grade 8
G11007 1 Lock Nut, ⅜"-24, C Grade
10. G3303-98 1 Chain, No. 41, 98 Pitch Including Connector Link
G3303-16 1 Chain, No. 41, 16 Pitch Including Connector Link
(Used W/Row Extension Unit Brackets)
GR0196 1 Connector Link, No. 41
11. GD1026 1 Sleeve, 1 3∕16" Long
12. G10201 1 Special Washer, ⅜" x 1 ½ " O. D.
13. GD1065 1 Idler Spring
14. GD7318 1 Sleeve, 1" Long
15. G10108 1 Lock Nut, ⅜"-16
16. G10210 1 Washer, ⅜" USS
17. GD11962 1 Idler
18. G10003 3 Hex Head Cap Screw, ⅜"-16 x 1½"
G10108 3 Lock Nut, ⅜"-16
19. GD10867 2 Stop
20. G10326 1 Hex Head Cap Screw, ⅜"-16 x 3¾"
21. G10551 1 Clevis Pin, ¼" x 2½"
G10669 1 Hair Pin Clip, No. 22
22. G10312 2 Carriage Bolt, 5∕16"-18 x¾"
G10620 2 Serrated Flange Nut, 5∕16"-18
23. GD1033 1 Shield
24. - See "Gauge Wheels", Pages P6 And P7
25. GA10157 1 Shank W/Gauge Wheel Pivot Spindle And Set Screw
GD11001 - Spindle
G10438 - Hex Head Cap Screw, ½"-13 x¾"
26. G10207 2 Washer, ⅞" O. D. x 13∕32" I. D. x .134" (If Applicable)
27. GD11845 1 Dust Cap
28. See "KPM I Electronic Seed Monitor" ,"KPM II Stack-Mode Electronic
Seed Monitor" And "KPM III Electronic Seed Monitor", Pages P64-P69
29. GB0285 1 Collar, Depth Adjustment
30. GB0265 1 Pivot Link, Depth Adjustment
31. GD15970 1 Sun Shade
32. G10304 1 Carriage Bolt, ⅜"-16 x 3"
G10108 1 Lock Nut, ⅜"-16
33. GD16245 - Sun Shade (Rubber)
